| DRILL PRESS | |
| Max Drilling Diameter (mm) | Φ16mm (5/8”) |
| Motor Power | 550W |
| Spindle Travel (mm) | 85 |
| Class Of Speed | 16 |
| Speed 50/60Hz | 180-2770/220-3320 RPM |
| Spindle Taper | MT2 |
| Max. distance from spindle axis | |
| to surface of column (mm) | 180 |
| Max. distance from spindle end | |
| to surface of table (mm) | 640 |
| Max. distance from spindle end | |
| to surface of base (mm) | 1175 |
| Swing (mm) | 360 |
| Table Size (mm) | 290 X 290 |
| Base Size (mm) | 460 X 272 |
| Column Diameter (mm) | Φ72 |
| Height (mm) | 1600 |
| Net Weight/Gross Weight (kgs) | 70/74 |
| Packing Size (mm) | 1140 X 490 X 270 |
