La Padana Co-Axial Screw Compressor MXP1500-500E, 500L, 15Hp, 3ph, 54CFM -w- Dryer
Details
Industrial Co-Axial Screw Compressor with Dryer
Direct Drive Silent Co-Axial Screw Compressor with Oil separator filter SPIN-ON, Oil/air cooling through electrically aired radiator, No-load operation with timed stop, Delta-star starting, Electronic control card, Equipped with a valve and tank linking line.
- Pressure: 10 Bar / 145 PSI
- Type: Co-Axial Screw Compressor
- Nominal Motor Rating: 15 Hp / 11 kW
- Voltage: 400V / 3ph / 50hz (approx 18.5A load at 0.85 lag PF per phase)
- Air Displacement: 1,500 l/min / 54 CFM / 90 m3/h
- Tank: 500 litres
- Weight: 367 kg
- Package Dimensions: 73 x 195 x 173 cm
